Speed Controller (Panel Mount Version)

Item # CC-01 — Speed Controller (Panel Mount Version)

All Downloads

The Speed Controller is a low-cost manual velocity controller designed to interface between 12 or 24V battery power and a remote grounded proportional solenoid valve. It is available in a direct panel mount for remote control of a proportional solenoid or packaged in a metal box for remote mounting. Reverse polarity protection and short circuit protection is provided.

Our products are designed to be customized by our customers and can be thought of as product foundations. Find the foundational product(s) that you need in our catalog, add them to your quote cart, then explain your requirements for your project on the quote cart submission form. If you cannot find the foundational product, please tell us your requirements.

Add to Quote

QTY

Specifications

Order Code

P/N: CC-01 (panel mount version)

No. of Output(s)

Dither Amplitude Fixed

10% (Fixed)

Current Dither Frequency Fixed

180 Hz (Fixed)

Proportional And On Off Solenoid

1 (2A)

Solenoid Selection Nominal

Solenoid selection should comply with: (Vpower supply – 1.5V)/I-max = R coil.

Regulated Current Output

2 Amps (Adjustable)

Operating Voltage

12 or 24 VDC nominal (9 to 32 VDC)

Reverse Polarity Protection

Inherent in Design

Short Circuit Protection

Provided

Enclosure

PCB

Dimensions

63.7 x 63.7 x 48.2 mm
2.50 x 2.50 x 1.89 Inches
(W x L x H)

No. of Connections

Connection(s)

BLACK - Output + 24 in. of 18 AWG lead wires
GREEN - Power GND and Output GND
RED - Power +

Operating Temperature

-40 to 85 ºC
-40 to 185 ºF

Applications

Material handling equipment
Aerial lift platforms
Mobile agricultural equipment
Proportional hydraulic circuits in a variety of mobile and industrial applications

Analog Input

Potentiometer

Maximum Current Adjustable

600 to 2000 mA (10 Turn Trim Pot)
Increases as Trim Pot is Turned Clockwise

Minimum Current Adjustable

0 to 500 mA (10 Turn Trim Pot)
Increases as Trim Pot is Turned Clockwise

No. of Inputs

More +

Downloads

Datasheet

CC-X Datasheet

Compliance

RoHS - DoC - All Compliance

LVD - DoC - All Compliance
